Chevrolet Equinox Service Manual: Special Tools

Special Tools Parking Brake

IllustrationTool Number/ DescriptionJ-21177-ADrum-to-Brake Shoe Clearance GaugeJ-37043Parking Brake Cable Release ToolJ-38400Brake Shoe Spanner and Spring Remover ...

Special Tools Disc Brakes

IllustrationTool Number/ DescriptionJ-39544-KITComplete Torque Socket Set –10-PiecesJ-41013Rotor Resurfacing KitJ-42450-AWheel Hub Resurfacing KitJ-45101Hub and Wheel Runout GaugeJ-45101-100Conical ...
